Setting Types

Every editable control in FilamentCraft — whether it lives in a section's settings panel or a theme's template-settings panel — is declared with a small PHP DSL. Each control is a Setting subclass under FilamentCraft\Settings\Types, instantiated with a make('id') call and configured fluently:

use FilamentCraft\Settings\Types\Text;

Text::make('heading')
    ->label('Heading')
    ->default('Welcome')
    ->required();

The editor compiles each Setting into a real Filament v4 form component at runtime, so the inputs you get are the same battle-tested fields Filament renders everywhere else — wired up for FilamentCraft's live-preview bus.

A section's settings panel — every control here started life as a one-line Setting declaration, grouped with Group dividers.

The 18 built-in types

Type	Class	Page
Text	Text	Text inputs
Textarea	Textarea	Text inputs
Number	Number	Text inputs
Range	Range	Text inputs
Select	Select	Choice inputs
Radio	Radio	Choice inputs
Checkbox	Checkbox	Choice inputs
Enum buttons	EnumButtons	Choice inputs
Color	Color	Color inputs
Color scheme	ColorScheme	Color inputs
Color scheme group	ColorSchemeGroup	Color inputs
Font	Font	Font picker
Image	Image	Media & content
Icon	Icon	Media & content
Link	Link	Media & content
Rich text	RichText	Media & content
Group	Group	Layout & structure
Category	Category	Layout & structure

Shared API (every type)

All setting types inherit the same base methods from FilamentCraft\Settings\Setting:

Method	Purpose
make(string $id)	Construct the setting. The id must match /^[a-z0-9_][a-z0-9_-]*$/i.
label(string $label)	The field label shown in the editor.
default(mixed $value)	The value used until the user changes it.
info(string $text)	Helper text rendered under the field.
required(bool $value = true)	Mark the field required.
visibleIf(array $predicates)	Show the field only when other fields match — e.g. ->visibleIf(['cta_enabled' => true]).
cssVar(string $name, ?string $unit = null)	Bind the value to a CSS custom property in <style id="fc-tokens">. The optional unit is appended to numeric values.

cssVar() is what makes a setting themeable: the resolved value is written to :root as a CSS variable so your section Blade and theme CSS can read it. See Theme Authoring for the full token pipeline.

Range::make('button_radius')
    ->cssVar('--button-radius', 'px')
    ->min(0)->max(24)->default(8);
// emits:  --button-radius: 8px;

Live-update behaviour

When a setting changes in the editor, FilamentCraft pushes the change to the preview iframe. The SchemaCompiler chooses one of two Livewire live modes per type — you never configure this, it is automatic:

• Instant live() — fires on every change. Used for discrete, one-click inputs: Checkbox, Radio, EnumButtons, Select, ColorScheme, Font, Icon.
• Lazy live(onBlur: true) — defers the round-trip until the field loses focus. Used for typed/dragged/uploaded inputs where a half-finished value shouldn't trigger a re-render: Text, Textarea, Number, Range, Color, Image, Link, RichText.

The lazy mode matters most for RichText: Filament v4's TipTap editor throws if the surrounding DOM is morphed mid-keystroke, so the round-trip is deferred to blur.

Where settings are used

• In a section — return them from the static settings() method. See Custom Sections. Section settings can also mix in raw Filament v4 components (e.g. Toggle, ColorPicker) alongside the DSL.
• In a theme — return them from settingsSchema(), usually wrapped in Category groups. See Theme Authoring.
